Key Features Of 12v 120ah LiFePO4 Battery Pack:
Longer service life. More than 3000 cycle times..About 7-8 years lifespan.
Plug in replacement of lead acid battery
High discharge rate capability.Max continous discharge 175A. Peak discharge 320A
Support parallel and series to make higher voltage and capacity.
Fast charge.Can be safely rapidly recharged in 1-3 hours
Lighter weight. About 1/3 the weight of lead acid.
Maintenance free
Low self discharge rate. Lower than 3% monthly
Deep cycle. Can be 100% deep discharged.
IP65 waterproof rating.Suitable for marine use
Safest performance. Lifepo4 is the safest lithium material. No fire or explosion
Intelligent Battery Management System(BMS)
1. Over charge protection function
2. Over discharge protection function
3. Over current protection function
4. Short protection function
5. Over temperature protection function
6. Automatic cell balance function
12.8V LiFePO4 Series Battery Applications
Solar/wind Energy storage system
Golf carts
Recreational Vehicles(RVs)
Marine machine
UPS Backup power system
Solar street light
→HyXin-LFP-LiFePO4-12.8V-120Ah-Battery-Pack-Specification
120AH 12V LiFePO4 Series Battery Applications
Solar/wind Energy storage system
Golf carts
UPS Backup power system
Solar street light
Recreational Vehicles(RVs)
Marine machine
The 120Ah 12.8V high rate LiFePO4 battery is specially designed as a drop-in replacement to lead acid batteries. The 120Ah 12.8V LiFePO4 battery delivers omrepower, faster charging and longer life than comparable lead acid batteries. With high efficiency and ultra-fast charging and discharging capabilities, the The 120Ah 12.8V Lithium iron phosphate battery is an ideal solution for industrial applications where a long services and quick charing is needed.
| 12.8V 120Ah LiFePO4 Battery Specification Datasheet | |
| Item | General Parameters |
| Rated Capacity | 120AH @0.5C to 10.8V |
| Stored energy | 1536Wh |
| Cycle life@100%DOD | 2000+ Cycles |
| Approx. Weight | 14kg |
| Internal Resistance | ≤35.0 mΩ |
| Max. Charge Current | 100 A |
| Max. Discharge Current | 100 A |
| Charge Cut-off Voltage | 14.6V |
| Discharge Cut-Off Voltage | 10.8V |
| Dimensions | L260mm×W180mm×H247mm |
| Low temperature self heating | Avaliable(0~-20°C) |
| Operating Temperature Range Charge |
-4°F (-20°C) to 113°F (45°C) |
| Discharge | -4°F (-20°C) to 140°F (60°C) |
| Recommended | 59°F (15°C) to 95°F (35°C) |
| Self-Discharge Rate | ≤3%/month |
| Life Expectancy (years) | 10 years @25°C in 80%DOD |
| Self Discharge | Approx. 2% per month @ 25°C |
| Long Term Storage | Charge every 6 months |
| Short Circuit Protection | Automatically recover after removal of short |
| Terminal Type | Female Copper Insert M8 (M8/mm) |
The lead time for standard cell orders is 3-7 working days for fast delivery within the United States and the European Union. For custom battery packs, the estimated lead time for the entire development, production, and delivery process is 25-30 working days. However, if your battery pack has more complex technical requirements, this lead time may be extended. Please consult our team for more detailed information.
Choose HYXinbattery as your supplier for energy storage solutions. Our factory excels in expertise, production capabilities, and adherence to industry standards. With streamlined logistics, we ensure timely delivery and offer flexible customization options to meet your specific needs. Trust our proven track record for reliable products and efficient service. Experience the advantages of HYXinbattery: superior quality, on-time delivery, and tailored solutions.
In our products, we use cells from EVE, CATL, Gotion, REPT and other well known brands. The most important process is determining the right cells for each customer’s unique battery pack needs, and our Research & Development team is well equipped to make those determinations.
We provide a warranty of 3 years for our cells and battery packs. In the unlikely event of any defects, we will replace the batteries. However, please note that we do not offer warranty coverage for batteries that have been improperly maintained. This includes cases of incorrect polarity, improper installation, overheating during storage or usage, physical damage, fire, freezing, water damage, tampering, terminal damage, failure to properly charge the battery, or exceeding the rated charge/discharge cycles.
Absolutely! At HYXinbattery, we offer customization options to meet your specific requirements. Whether it’s incorporating your company’s logo or branding elements onto the battery packs, we can handle it seamlessly. Our team of experts will work closely with you to ensure that your customization needs are met with precision and professionalism. Rest assured, we understand the importance of your brand identity and will handle it with utmost care and attention to detail. Choose HYXinbattery for personalized solutions that reflect your unique brand image.
When it comes to choosing transportation methods, we at HYXinbattery prioritize safety, efficiency, and cost-effectiveness. Our experienced logistics team carefully assesses various factors such as distance, volume, and urgency to determine the most suitable transportation method for your specific needs. We have established reliable partnerships with reputable shipping companies and freight forwarders, ensuring secure and timely delivery of our products. Rest assured, we will select the optimal transportation method that guarantees the safe and efficient transportation of your orders, while considering your budgetary requirements. Trust us to handle your transportation needs with utmost professionalism.
Payment Methods: T/T(support deposit card). Paypal (support credit card)
Payment Handling Fee: Payment via PayPal (4.7% extra PayPal Cost). Payment via T/T ($30 extra for each payment)
At HYXinbattery, we prioritize the safe delivery of our products. We provide insurance coverage for shipments, ensuring that you are protected in case of any unforeseen circumstances during transit. Additionally, we offer a tracking number for all shipments, allowing you to monitor the progress of your order in real-time. With our insurance coverage and tracking system in place, you can have peace of mind knowing that your products will arrive safely and that you can track their journey until they reach your destination.
At HYXinbattery, we utilize high-quality LiFePO4 cells in our battery packs. These cells are known for their exceptional safety, long cycle life, and high energy density. We carefully select and source LiFePO4 cells from reputable manufacturers to ensure the reliability and performance of our battery packs. Such as EVE, CATL, BYD, Gotion, Gangfeng, REPT, Topband, CALB etc.,
When it comes to choosing transportation methods, we at HYXinbattery prioritize safety, efficiency, and cost-effectiveness. Our experienced logistics team carefully assesses various factors such as distance, volume, and urgency to determine the most suitable transportation method for your specific needs. We have established reliable partnerships with reputable shipping companies and freight forwarders, ensuring secure and timely delivery of our products. Rest assured, we will select the optimal transportation method that guarantees the safe and efficient transportation of your orders, while considering your budgetary requirements. Trust us to handle your transportation needs with utmost professionalism.
We are pleased to offer chargers to our valued clients who purchase batteries from us. However, we regret to inform you that we are unable to provide chargers separately for standalone purchases. Please note that we will include the cost of battery chargers in the invoice when you purchase batteries from us. For further information, we recommend consulting our team. Thank you for your understanding.
At HYXinbattery, we guarantee a good quality battery pack through the following key factors:
1. Superior Cell Selection: We carefully choose high-quality lithium-ion cells from trusted suppliers known for their reliability and performance.
2. Stringent Quality Control: Our manufacturing processes adhere to strict quality control measures, ensuring consistent and precise assembly of battery packs.
3. Advanced Battery Management System (BMS): Our battery packs are equipped with an advanced BMS that provides overcurrent protection, short-circuit protection, temperature detection protection, and balancing functionality, ensuring safe and efficient operation.
4. Extensive Testing: We conduct comprehensive testing, including performance, safety, and reliability assessments, to verify the quality and durability of our battery packs.
5. Experienced and Certified Factory: Our state-of-the-art factory follows industry standards and certifications, ensuring high-quality manufacturing processes and safe transportation of our batteries.
By focusing on these factors, we guarantee that our battery packs meet the highest standards of quality, safety, and performance, providing our customers with a reliable and long-lasting energy storage solution.
Our clients have consistently praised HYXinbattery for its exceptional performance and reliability. They appreciate the battery’s long lifespan, cost-effectiveness, and convenient Bluetooth monitoring capabilities. The reliable BMS system with features such as overcurrent protection, short-circuit protection, and temperature detection has been highly regarded for ensuring safety. The high energy density and long cycle life of the LiFePO4 cells used in HYXinbattery packs have also received positive feedback. Overall, clients value HYXinbattery for its quality, innovation, and commitment to providing reliable home energy storage solutions.
Main battery types: Lithium batteries, LiFePO4 batteries, custom LiFePO4 battery packs, All-in-one ESS home solar battery system.
Main Applications: E-bikes, RVs, Golf Cars, Touring cars, E-scooters, Forklifts, Sweepers, Yachts, Vehicle devices, E-mobility equipments, Marine, Household Energy system and RV Solar system.
